HEROG2-HB77high bay light

High efficiency up to 200lm/High luminous flux up to 40000lm.
Costs-effective modern design.
Plug & play 12V PIR/ Microwave sensor.
IP65.

APPLICATIONS
WarehouseIndustrial FacilityExhibition CenterGymnasium
Airport

Share with friends

Model No.		HB77-100W	HB77-150W	HB77-200W
Power Consumption		60W-100W	100W-150W	150W-200W
Product Dimension		φ240*166(mm)	φ280*166(mm)	φ320*166(mm)
Efficiency		150±10lm/W
Luminous Flux (±10%)		15000±1000lm	22500±1500lm	30000±2000lm
High Efficiency		180±10lm/W
High Luminous Flux (±10%)		18000±1000lm	27000±1500lm	36000±2000lm
CCT		3000K;4000K;5000K;5700K;6500K
Ingress Protection		IP65
Color Rendering Index		Ra>80
Beam Angle		60°/ 90°/ 120°
Driver Brand		TOMCARLINE
Input Voltage		AC100-277V/ AC200-240V
Power Factor		0.95
Frequency		47-63HZ
Driver Type		Constant Current (CC)
Luminaire Net Weight		1.9kg	2.4kg	3kg
Packing Information		1PCS/CTN	1PCS/CTN	1PCS/CTN
Export Carton Size		292917CM	333317CM	373717CM
Gross Weight		2.4kg	3kg	3.8kg
Material	Housing	Aluminum Alloy
	Optics	PC lens
Finish		Powder Coating
Fixture Color		Black
Mounting Option		Hook Hanging / Ceiling Mounting
Storage temperature range		-30℃- +70℃
Storage humidity range		85% max.
Operating temperature range		-30~+50℃
Operating humidity range		85% max.
Life Time		50,000 hours
Warranty		5 Years
Dimmable		1-10V dimmable
Intelligent Control		Plug & play 12V PIR / Microwave sensor
Optional Accessories		1-10V dimmable
		Plug & play 12V PIR / Microwave sensor + Remote control
		CRI > 90 optional
		±45° adjustable brackets
		PC reflector
		Aluminum reflector
		Safety rope (0.5m length)
